UPLUS Hot Products Part 2: 480BSWF, PZ1940, MINI 740 & PIXEL BAR 500

Compare UPLUS 480BSWF, PZ1940, MINI 740 and PIXEL BAR 500. Explore framing, Bee Eye, RGBW wash, warm LED effects and professional stage applications.

Welcome to Part 2 of UPLUS Lighting's Hot Products Series, where we introduce professional stage lighting fixtures designed for different production requirements. Following our previous article on popular moving head lights from UPLUS Lighting, this edition highlights four additional models: the 480BSWF LED framing moving head, PZ1940 RGBW Bee Eye moving head, MINI 740 compact moving head, and PIXEL BAR 500 warm-white and amber LED bar. Each fixture offers different optical functions, lighting effects, and installation advantages for professional rental companies, lighting designers, distributors, and event production teams.

Exploring the Versatile 480BSWF Cutting Light

The 480BSWF is a professional 480W LED Beam Spot Wash Framing moving head designed for productions that require precise beam shaping and flexible optical effects. It features a 4.5°–55° zoom range, CMY color mixing, CTO adjustment, seven rotating gobos, eight fixed gobos, a rotating five-facet prism, and an animation wheel. Its framing system uses eight independently controlled blades to create different projected shapes and lighting areas. With 540° pan movement, optional 630° pan configuration, and 270° tilt movement, the fixture can support concerts, theaters, and live event productions. For detailed channel information, installation requirements, and optical specifications, refer to the official 480BSWF technical manual.

But what exactly makes the 480BSWF so special? Let’s break down its features:

  • Maximum Focusing Angle : 55°
  • Minimum Angle : 4.5°
  • X and Y Axis Rotations : 540° and 270° respectively
  • Auto Repositioning : Ensures precision
  • CTO and CMY Functions : For versatile color mixing
  • Pattern Plates : 7 rotating and 8 fixed
  • Prism Plates : 5
  • Cutting System : 1 set of all-directional framing system with 8 independent blade precise position
  • Electronic Iris : 5-100%
  • Animation Wheel : Adds to its functionality

With its myriad features, the 480BSWF is not just another cutting light. Its advanced cutting system allows for precise framing, making it perfect for complex stage designs. Whether you’re lighting a concert, theatre production, or a corporate event, the 480BSWF delivers with consistency and precision. The ability to create different shapes and patterns adds a dynamic element to any performance, capturing the audience’s attention and enhancing the visual experience.



700 BSWF 9

Why the PZ1940 RGBW Bee Eye Moving Head Is a Popular Choice

The PZ1940 19×40W RGBW Bee Eye Zoom Wash Moving Head combines wash lighting, narrow beam-style effects, and rotating Bee Eye patterns in one professional indoor fixture. Equipped with nineteen 40W RGBW 4-in-1 LEDs, the moving head supports individual LED pixel control, adjustable zoom, 0–25Hz strobe effects, and multiple DMX channel modes. Its 13.6kg net weight and compact design make it an option for indoor concerts, nightclubs, theaters, and stage lighting rental applications. The current product page lists a 4°–45° zoom range and IP20 protection, so the fixture should be used in dry indoor environments.

  • LED Source : 19*40W RGBW 4-in-1 LED
  • Zoom Angle : 4°-55°
  • Effects : Wash, beam, bee eye 3-in-1
  • Strobe : 0-25Hz
  • DMX Channels : 22/36/79/98/93
  • Dimmer : 0-100% linear
  • Pan and Tilt : 540° + 16 bit fine and 270° + 16 bit fine
  • Display : LCD colorful
  • IP Rating : IP20
  • Dimensions : 338 263 417mm
  • Net Weight : 13.6kg

The PZ1940 is not just a dyeing lamp; it is a powerhouse of effects and versatility. Its 4-in-1 LED source provides rich and vibrant colors that can transform any stage into a visual spectacle. The zoom angle flexibility from 4° to 55° allows for both focused beams and wide washes, making it suitable for various stage sizes and applications. The PZ1940’s lightweight design means it can be easily transported and set up, which is a significant advantage for touring companies and events with tight schedules.

Moreover, the PZ1940’s strobe function, with a range of 0-25Hz, adds an extra layer of excitement to performances, creating dramatic and pulsating effects that sync with music or action on stage. The multiple DMX channels offer extensive control options, allowing lighting technicians to customize the lamp’s output precisely. Whether it’s for a concert, theatre production, or corporate event, the PZ1940 delivers consistent performance and stunning visuals.

For more details on the PZ1940, check out these [videos]( https://www.youtube.com/watch?v=561QmQ4ZYd0&t=18s , https://www.youtube.com/watch?v=HO3wpzyaxyc&t=40s  ).

The MINI 740: A DJ’s Delight

The MINI 740 Version 3 7×40W RGBW Moving Head with LED Ring Control provides a compact lighting solution for indoor DJ performances, nightclubs, and entertainment venues. Featuring seven 40W RGBW 4-in-1 LEDs and a 4.5°–45° zoom range, this version combines wash lighting with additional LED ring effects. Its 540° pan and 270° tilt movement allow lighting technicians to create dynamic sequences through compatible professional control systems. With a net weight of approximately 5.75kg and IP20-rated construction, it is designed for dry indoor stage applications where compact dimensions and creative lighting effects are important.

  • LED Source : 7*40W RGBW 4-in-1 LED
  • Zoom Angle : 4.5°-45°
  • Effects : Wash, beam, bee eye, pixel
  • Strobe : 0-25Hz
  • Control : DMX512/Auto Run/Master-Slave/Music
  • DMX Channels : 23/35/51
  • Dimmer : 0-100% linear
  • Pan and Tilt : 540° + 16 bit fine and 270° + 16 bit fine
  • Display : LCD colorful
  • IP Rating : IP20
  • Dimensions : 340 273 170mm
  • Net Weight : 5.75kg

The MINI 740 series is available in three versions designed for different lighting applications. Version 1 focuses on zoom, Bee Eye, and individual LED pixel effects, with 23/35/51-channel DMX modes. Version 2 emphasizes zoom wash and full-on lighting effects, using 11/17-channel modes. Version 3 adds LED ring control effects and additional network control options, depending on the supplied configuration. All three versions use seven 40W RGBW LEDs and share a 4.5°–45° zoom range, but their visual effects and control requirements differ. Read our complete comparison of the three MINI 740 moving head versions to select the most suitable configuration for your stage or rental project.

One of the standout features of the MINI 740 is its multiple control options, including DMX512, Auto Run, Master-Slave, and Music mode. This flexibility allows DJs to sync the lighting effects with their music, creating an immersive experience for the audience. The LED ring control effect adds an extra layer of visual appeal, making the MINI 740 a must-have for any DJ setup.

Product Introduction  Three MINI740

For more details on the MINI 740, check out these [videos]( https://www.youtube.com/watch?v=UyZf3U-0gsg&t=37s , https://www.youtube.com/watch?v=Pupb5WIsFC8 , https://www.youtube.com/watch?v=K6jVgaVLH8Q ).

PIXEL BAR 500: Perfect for Bars and Forum Speeches

The PIXEL BAR 500 Indoor 10×50W Warm White and Amber COB LED Bar is designed for indoor stage lighting applications requiring warm color tones and controlled linear lighting effects. Equipped with ten 50W dual-color COB LEDs, the fixture combines 2800K warm-white and amber lighting with individual LED control, adjustable dimming, and variable-speed strobe effects. Available lens options include 12°, 24°, 36°, and 60° configurations for different beam coverage requirements. Its rigid aluminum housing and multiple mounting options make it suitable for indoor bars, theaters, conference stages, entertainment venues, and live performances.

  • Light Source : 10PCS 50W Amber + 2800K 2-in-1 COB LEDs
  • DMX Channels : 4/7/14/25/1/2/5/10/20
  • Dimmer : High-resolution dimmer 0-100%
  • Lenses : 68.9mm with 12/24/36/60-degree options
  • CTO : 2800K-1800K
  • Operation : Setup and addressing via LED display and 4 buttons
  • Pixel Pitch : 94mm
  • Strobe Effect : Variable speed (1-20Hz)
  • Control Mode : DMX512, Auto Run, Master/Slave, Sound active
  • IP Rating : IP20
  • Net Weight : 5.8kg

The PIXEL BAR 500 is designed for versatility and ease of use. Its long, slim design makes it ideal for creating smooth, even washes on walls and stages. The 10PCS 50W Amber and 2800K 2-in-1 COB LEDs provide a rich, warm light that can enhance the ambiance of any venue. The high-resolution dimmer allows for precise control over light intensity, making it perfect for subtle mood lighting or more dramatic effects.

For outdoor events, the protection rating and lighting configuration must be considered when choosing an LED pixel bar. The PIXEL BAR 500 is an IP20 indoor fixture intended for dry environments. Customers who require a waterproof pixel bar can also explore the IP-PIX500 IP65 10×50W LED Pixel Link Bar, which is available with RGBW four-in-one LEDs or cool-white and warm-white two-in-one LEDs. The IP-PIX500 offers individual LED pixel control, four-sided linking options, and weather-resistant construction for appropriately installed outdoor productions. However, the IP-PIX500 is a separate model with different light source configurations, rather than an identical waterproof version of the warm-white and amber PIXEL BAR 500.

PIXEL BAR 500 7

For more details on the PIXEL BAR 500, check out this video .

Comparative Analysis: How Do These Lamps Stand Out?

The four lighting fixtures in this article serve different professional stage lighting needs. The 480BSWF provides Beam, Spot, Wash, and Framing functions for precise light shaping. The PZ1940 offers RGBW wash effects, individual pixel control, and rotating Bee Eye patterns. The MINI 740 provides compact moving head options for indoor DJ performances and smaller entertainment stages, while the PIXEL BAR 500 creates warm-white and amber lighting effects for stage backgrounds and atmospheric illumination. When designing a complete lighting system, professional teams should consider stage dimensions, fixture placement, control channels, beam characteristics, and the required visual effects. Explore UPLUS Lighting's professional concert and stage performance lighting solutions to learn how different fixture types can be combined in live productions.

The 480BSWF’s advanced cutting system and wide focusing angle make it a standout choice for detailed stage work. Its ability to create various shapes and patterns enhances the visual dynamics of any performance. On the other hand, the PZ1940’s combination of wash, beam, and bee eye effects, along with its lightweight design, makes it a versatile and easy-to-use option for various stage sizes.

The MINI 740, with its compact size and multiple control options, is perfect for DJs looking to add a visual element to their sets. Its powerful output and dynamic effects make it a crowd favorite. Lastly, the PIXEL BAR 500’s long, slim design and rich lighting effects make it ideal for creating immersive environments in bars and forums. Its adaptability and ease of use ensure that it can meet the demands of various events and settings.

The Bottom Line

Looking for professional stage lighting fixtures for your next concert, nightclub, theater, or rental equipment project? UPLUS Lighting offers different options, including the 480BSWF LED Framing Moving Head, PZ1940 RGBW Bee Eye Moving Head, MINI 740 compact moving head series, and PIXEL BAR 500 warm-white and amber LED bar. Each model provides different optical effects, DMX configurations, and installation requirements. Whether you are a distributor, rental company, lighting designer, or event production contractor, our team can help you compare product specifications, confirm suitable versions, and discuss packaging, customization, and bulk quotations. Contact UPLUS Lighting for stage lighting product details, technical support, and professional quotations today to find suitable lighting solutions for your next project.
