IN-PIX200 Indoor two row 20*10W RGBW led pixel link bar
The indoor two-row 20*10W RGBW led pixel link bar features dual-row LEDs that provide ample brightness, support pixel-level independent light control and joint adjustment, and offer diverse lighting effects, making it suitable for indoor settings such as stages, bars, and studios.
Specifications
OPTICS
•AC90-240V, 50/60HZ
•200W power consumption
•20 x10W RGBW 4IN1 LED
•50,000 hours expected lifetime
•6°,10°,15°,25°,40° optional beam angle, regular do 15°
•IP20 rate
FEATURES
•Each LED can be controlled individually
•DMX512, RDM, Master-Slave, Auto
•12/92/04/80DMX channels
•0-100% 8/16bit linear dimming
•1-20 times/second strobe
SPECIFICATION
•Dimension:500*100*82mm; NW: 5.2kgs
Effect
Features
APPLICATION
Packaging & Logistic
Frequently Asked Questions
Explore our FAQ section for clear guidance on orders, shipping, customization, and after-sales service.
Our service?
We have a professional team that can provide and customize products for you.
Can I visit Uplus Lighting company onsite?
Of course, our company is located at No. 4, Xiaotang Middle Road, Jianggao Town, Baiyun District, Guangzhou, China. Welcome to visit our factory!
Are you a manufacturer or a trading company?
We come directly from the factory and also have a sales office in Baiyun, Guangzhou.
What is Uplus Lighting's main product for factories?
The main products provided by Uplus are stage lighting, related accessories, and consoles. Our products are suitable for many large-scale international performances, concerts, theaters, music festivals, TV programs, etc.
Is the IN-PIX200 suitable for indoor stage and rental installations?
The IN-PIX200 is rated IP20 and includes an Omega quick-lock bracket system and LCD display. It measures 500 × 100 × 82 mm and weighs 5.2 kg.
